Actual/Setpoint
Signalbezeichnung
HeatingSettings.Cor_HS3Curve_X5
HeatingSettings.Cor_HS3Curve_X6
HeatingSettings.Cor_HS3Curve_X7
HeatingSettings.Cor_HS3Curve_X8
HeatingSettings.Cor_HS3Curve_Y1
HeatingSettings.Cor_HS3Curve_Y2
HeatingSettings.Cor_HS3Curve_Y3
HeatingSettings.Cor_HS3Curve_Y4
HeatingSettings.Cor_HS3Curve_Y5
HeatingSettings.Cor_HS3Curve_Y6
HeatingSettings.Cor_HS3Curve_Y7
HeatingSettings.Cor_HS3Curve_Y8
Heating1. Cor_HS3ParallelTransfer
HeatingActual.Cor_HS3RoomTemp
HeatingSettings.Cor_HS3RoomSetP
HeatingActual.Cor_HS3ReturnTemp
HeatingActual.Cor_HS3PumpARun
HeatingActual.Cor_HS3PumpBRun
HeatingActual.Cor_HS3PumpAStart
HeatingActual.Cor_HS3PumpBStart
HeatingActual.Cor_HS3CV1
HeatingActual.Cor_HS3PID_Output
HeatingSettings.Cor_HS3PumpDay-
Limit(0)
20/92
Modbus-
Typ
BACnet
Adresse
I,3
39
I,3
40
I,3
41
I,3
42
I,3
43
I,3
44
I,3
45
I,3
46
I,3
47
I,3
48
I,3
49
I,3
50
R,3
537
R,4
12
AV,
40012
R,3
51
AV,
30051
R,4
13
AV,
40013
L,2
15
BV,
20015
L,2
16
BV,
20016
L,2
107
L,2
108
R,4
155
R,4
162
AV,
40162
R,3
523
Default-
Beschreibung
Wert
0°C
Outdoortemp for fifth curvepoint for
outdoor compensated setpoint HS3
5°C
Outdoortemp for sixth curvepoint for
outdoor compensated setpoint HS3
10°C
Outdoortemp for seventh curvepoint for
outdoor compensated setpoint HS3
15°C
Outdoortemp for eighth curvepoint for
outdoor compensated setpoint HS3
67°C
Setpoint for first curvepoint for outdoor
compensated setpoint HS3
63°C
Setpoint for second curvepoint for out-
door compensated setpoint HS3
59°C
Setpoint for third curvepoint for outdoor
compensated setpoint HS3
55°C
Setpoint for fourth curvepoint for out-
door compensated setpoint HS3
53°C
Setpoint for fifth curvepoint for outdoor
compensated setpoint HS3
43°C
Setpoint for sixth curvepoint for outdoor
compensated setpoint HS3
35°C
Setpoint for seventh curvepoint for out-
door compensated setpoint HS3
25°C
Setpoint for eighth curvepoint for out-
door compensated setpoint HS3
0 °C
Parallel transfer of setpointcurve HS3
Room temperature HS3
21°C
Setpoint room temperature HS3
Return temperature HS3
Is set if running pump HS3 P1A
Is set if running pump HS3 P1B
Start signal pump HS3 P1A
Start signal pump HS3 P1B
Control signal HS3 CV (0-10 V)
Controller output HS3 (0-100%)
17°C
Outdoor temp for pump stop day HS3
