flexotron800
7
Input/Output
7.1
Analogue inputs
Signalbezeichnung
HeatingActual.Cor_AnalogInput1(0)
HeatingActual.Cor_AnalogInput2
HeatingActual.Cor_AnalogInput3
HeatingActual.Cor_AnalogInput4
HeatingSettings.Cor_Ai1(0)
P100013568
Modbus-
Typ
BACnet
Adresse
R,4
43
R,4
44
R,4
45
R,4
46
X,4
51
Default-
Beschreibung
Wert
The scaled and filtered value of
AI1
The scaled and filtered value of
AI2
The scaled and filtered value of
AI3
The scaled and filtered value of
AI4
Connected signal on AI1:
0 = Disable
1 = Outdoor temp
2 = HS1 Supply Temperature
3 = HS2 Supply Temperature
4 = HS3 Supply Temperature
5 = CS1 Supply Temperature
6 = HW1 Supply Temperature
7 = HW2 Supply Temperature
8 = HP1 Supply Temperature
9 = HS1 Room Temperature
10 = HS2 Room Temperature
11 = HS3 Room Temperature
12 = CS1 Room Temperature1 =
PT1000
13 = CS1 Room Temperature2 =
0-10V
14 = HS1 Return Temperature
15 = HS2 Return Temperature
16 = HS3 Return Temperature
17 = CS1 Return Temperature
18 = HW1 Return Temperature
19 = HP1 Return Temperature
20 = Windspeed
21 = Differential Pressure
22 = Boiler Temperature;
Not Used in 3.2
23 = Boiler Return Temperature
24 = RH
25 = HP Supply Temperature
26 = HP Return Temperature
27 = CP Supply Temperature
28 = CP Return Temperature
29 = Extra sensor temp 1
30 = Extra sensor temp 2
31 = Extra sensor temp 3
32 = Extra sensor temp 4
33 = Extra sensor temp 5
34 = HB Supply Temp.
35 = HB1 Return Temp.
36 = HB2 Return Temp.
37 = HB3 Return Temp.
38 = HB4 Return Temp.
39 = Extra Circuit Sensor1
40 = Extra Circuit Sensor2
Input/Output
37/92
