Actual/Setpoint
5.2
Heating System 1 (HS1)
Signalbezeichnung
HeatingActual.Cor_HS1PID_Input
HeatingActual.Cor_HS1PID_SetP
HeatingSettings.Cor_HS1Curve_X1
HeatingSettings.Cor_HS1Curve_X2
HeatingSettings.Cor_HS1Curve_X3
HeatingSettings.Cor_HS1Curve_X4
HeatingSettings.Cor_HS1Curve_X5
HeatingSettings.Cor_HS1Curve_X6
HeatingSettings.Cor_HS1Curve_X7
HeatingSettings.Cor_HS1Curve_X8
HeatingSettings.Cor_HS1Curve_Y1
HeatingSettings.Cor_HS1Curve_Y2
HeatingSettings.Cor_HS1Curve_Y3
HeatingSettings.Cor_HS1Curve_Y4
HeatingSettings.Cor_HS1Curve_Y5
HeatingSettings.Cor_HS1Curve_Y6
HeatingSettings.Cor_HS1Curve_Y7
HeatingSettings.Cor_HS1Curve_Y8
16/92
Modbus-
Typ
BACnet
Address
R,4
2
AV,
40002
R,4
3
AV,
40003
I,3
1
I,3
2
I,3
3
I,3
4
I,3
5
I,3
6
I,3
7
I,3
8
I,3
9
AV,
30009
I,3
10
AV,
30010
I,3
11
AV,
30011
I,3
12
AV,
30012
I,3
13
AV,
30013
I,3
14
AV,
30014
I,3
15
AV,
30015
I,3
16
AV,
30016
Default-
Beschreibung
Wert
Supply temperature HS1
Outdoor compensated setpoint
supply temperature HS1
-20°C
Outdoortemp for first curvepoint
for outdoor compensated setpoint
HS1
-15°C
Outdoortemp for second
curvepoint for outdoor compensa-
ted setpoint HS1
-10°C
Outdoortemp for third curvepoint
for outdoor compensated setpoint
HS1
-5°C
Outdoortemp for fourth curvepoint
for outdoor compensated setpoint
HS1
0°C
Outdoortemp for fifth curvepoint
for outdoor compensated setpoint
HS1
5°C
Outdoortemp for sixth curvepoint
for outdoor compensated setpoint
HS1
10°C
Outdoortemp for seventh
curvepoint for outdoor compensa-
ted setpoint HS1
15°C
Outdoortemp for eighth curvepoint
for outdoor compensated setpoint
HS1
67°C
Setpoint for first curvepoint for out-
door compensated setpoint HS1
63°C
Setpoint for second curvepoint
for outdoor compensated setpoint
HS1
59°C
Setpoint for third curvepoint for
outdoor compensated setpoint
HS1
55°C
Setpoint for fourth curvepoint for
outdoor compensated setpoint
HS1
53°C
Setpoint for fifth curvepoint for out-
door compensated setpoint HS1
43°C
Setpoint for sixth curvepoint for
outdoor compensated setpoint
HS1
35°C
Setpoint for seventh curvepoint
for outdoor compensated setpoint
HS1
25°C
Setpoint for eighth curvepoint for
outdoor compensated setpoint
HS1
