Actual/Setpoint
Signalbezeichnung
HeatingSettings.Cor_HP1StopTemp
HeatingSettings.Cor_HP1TempDiff
HeatingActual.Cor_HP1PumpStart
5.8
Boiler Control
Signalbezeichnung
HeatingActual.Cor_BoilerTemp
HeatingActual.Cor_BoilerReturnTemp
HeatingSettings.Cor_BoilerStartTemp1
HeatingSettings.Cor_BoilerStartTemp2
HeatingSettings.Cor_BoilerStopTemp1
HeatingSettings.Cor_BoilerStopTemp2
HeatingActual.Cor_BoilerStart1
HeatingActual.Cor_BoilerStart2
HeatingSettings.Cor_BoilerStartHyst1
HeatingSettings.Cor_BoilerStartHyst2
HeatingSettings.Cor_BoilerStopHyst1
HeatingSettings.Cor_BoilerStopHyst2
HeatingActual.Cor_HB1Run(0)
HeatingActual.Cor_HB2Run
HeatingActual.Cor_HB3Run
HeatingActual.Cor_HB4Run
HeatingActual.Cor_HB1PumpRun
22/92
Modbus-
Typ
BACnet
Adresse
R,3
55
R,3
56
L,2
110
Modbus-
Typ
BACnet
Adresse
R,4 18
R,4 356
AV,
40356
R,3 57
R,3 58
R,3 59
R,3 623
L,2
112
L,2
113
R,3 624
R,3 625
R,3 626
R,3 627
L,2
242
BV,
20242
L,2
243
BV,
20243
L,2
244
BV,
20244
L,2
245
BV,
20245
L,2
246
BV,
20246
Default-
Beschreibung
Wert
55°C
Stop temperature for stop of load
pump HP1 on supply temperature
2°C
Difference temperature for stop of
load pump HP1 on return temperature
Start signal pump HP1
Default-
Beschreibung
Wert
Boiler temperature (3.1 or
earlier)
Boiler return temperature
45°C
Start temperature boiler for start
signal 1 (3.1 or earlier)
40°C
Start temperature boiler for start
signal 2 (3.1 or earlier)
55°C
Boiler stop temperature, for stop
signal 1 (3.1 or earlier)
55°C
Boiler stop temperature 2, for
stop signal 2 (3.1 or earlier)
Start signal 1 boiler (3.1 or
earlier)
Start signal 2 boiler (3.1 or
earlier)
2
Boiler start hyst.1, for start
signal 1(3.1 or earlier)
4
Boiler start hyst.2, for start
signal 2 (3.1 or earlier)
0
Boiler stop hyst.1, for stop sig-
nal 1(3.1 or earlier)
2
Boiler stop hyst.2, for stop sig-
nal 2(3.1 or earlier)
Run indication Boiler 1
Run indication Boiler 2
Run indication Boiler 3
Run indication Boiler 4
Run indication Boiler 1 pump
