Sauter flexotron800 V2 Benutzerhandbuch Seite 29

flexotron800
Signalbezeichnung
HeatingSettings.Cor_HBCurve_Y8
HeatingSettings.Cor_BoilerSetPCtrl
HeatingSettings.Cor_BoilerReturnTempLow
HeatingSettings.Cor_BoilerReturnTempHyst
HeatingActual.Cor_HBSupplyTemp
HeatingActual.Cor_HB1ReturnTemp(0)
HeatingActual.Cor_HB2ReturnTemp
HeatingActual.Cor_HB3ReturnTemp
HeatingActual.Cor_HB4ReturnTemp
HeatingActual.Cor_HB1Vessel(0)
HeatingActual.Cor_HB2Vessel
HeatingActual.Cor_HB3Vessel
HeatingActual.Cor_HB4Vessel
HeatingActual.Cor_HBReturnTCV1(0)
HeatingActual.Cor_HBReturnTCV2
HeatingActual.Cor_HBReturnTCV3
HeatingActual.Cor_HBReturnTCV4
HeatingActual.Cor_HBPID_SetP
HeatingActual.Cor_HBPID_Input
P100013568
Typ Modbus- BACnet Default-
Adresse
I,3 714
X,3 715
R,3 716
R,3 717
R,4 394 AV,
40394
R,4 395 AV,
40395
R,4 396 AV,
40396
R,4 397 AV,
40397
R,4 398 AV,
40398
R,4 401
R,4 402
R,4 403
R,4 404
R,4 405
R,4 406
R,4 407
R,4 408
R,4 409 AV,
40409
R,4 412 AV,
40412
Beschreibung
Wert
25°C Setpoint for first curvepoint for
outdoor compensated setpoint
HB8
0 Type of HB setpoint:
0 = Constant setpoint
1 = HS depending
2 = HS & HW depending
3 = HS & HP depending
4 = HS & HW & HP depending
5 = Outdoor comp. setp.
30 If boiler return temp is lower,
block the supply valves
5 Hysteresis when supply valves
is blocked before open
Boiler supply temperature
Return temperature Boiler 1
Return temperature Boiler 2
Return temperature Boiler 3
Return temperature Boiler 4
Control signal modulating boiler
1 (0-10 V)
Control signal modulating boiler
2 (0-10 V)
Control signal modulating boiler
3 (0-10 V)
Control signal modulating boiler
4 (0-10 V)
Return temp CV boiler 1 (0-10
V)
Return temp CV boiler 2 (0-10
V)
Return temp CV boiler 3 (0-10
V)
Return temp CV boiler 4 (0-10
V)
HB Actual setpoint
(HS depending or outdoor com-
pensated)
Supply temperature HB
Actual/Setpoint
29/92
