Signalbezeichnung
HeatingActual.Cor_OutDoorTemp(0)
HeatingActual.Cor_OutDoorTemp(0)
HeatingActual.Cor_HPSupplyTemp
HeatingActual.Cor_HPReturnTemp
HeatingActual.Cor_CPSupplyTemp
HeatingActual.Cor_CPReturnTemp
HeatingActual.Cor_ExtraSensor1
HeatingActual.Cor_ExtraSensor2
HeatingActual.Cor_ExtraSensor3
HeatingActual.Cor_ExtraSensor4
HeatingActual.Cor_ExtraSensor5
TimePro.TimeGroupHS1
TimePro.TimeGroupHS2
TimePro.TimeGroupHS3
TimePro.TimeGroupHW1
TimePro.TimeGroupHW2
TimePro.TimeGroupCor_ExtraTimeGroup1 L,2
TimePro.TimeGroupCor_ExtraTimeGroup2 L,2
TimePro.TimeGroupCor_ExtraTimeGroup3 L,2
TimePro.TimeGroupCor_ExtraTimeGroup4 L,2
TimePro.TimeGroupCor_ExtraTimeGroup5 L,2
TimePro.TimeGroupCS1
P100013568
Modbus-
BACnet Default-
Typ
Adresse
R,4 1
R,3 507 AV,
30507
R,4 358 AV,
40358
R,4 359 AV,
40359
R,4 360 AV,
40360
R,4 361 AV,
40361
R,4 362 AV,
40362
R,4 363 AV,
40363
R,4 364 AV,
40364
R,4 365 AV,
40365
R,4 366 AV,
40366
L,2 1
L,2 2
L,2 3
L,2 4
L,2 5
6
7
8
9
10
L,2 237
Beschreibung
Wert
Outdoor temperature
Outdoor temperature (can be mo-
dified if not connected to a physic
analogue input)
Heating Primary supply temperature
Heating Primary return temperature
Cooling Primary supply temperature
Cooling Primary return temperature
Additional sensor 1
Additional sensor 2
Additional sensor 3
Additional sensor 4
Additional sensor 5
Is set if timechannel comfort time
HS1 is active
Is set if timechannel comfort time
HS2 is active
Is set if timechannel comfort time
HS3 is active
Is set if timechannel comfort time
HW1 is active
Is set if timechannel comfort time
HW2 is active
Is set if timer output 1 is active
Is set if timer output 2 is active
Is set if timer output 3 is active
Is set if timer output 4 is active
Is set if timer output 5 is active
Is set if timechannel comfort time
CS1 is active
