flexotron800
Signalbezeichnung
Heating1.Cor_HS1ParallelTransfer
HeatingActual.Cor_HS1RoomTemp
HeatingSettings.Cor_HS1RoomSetP
HeatingActual.Cor_HS1ReturnTemp
HeatingActual.Cor_HS1PumpARun(0)
HeatingActual.Cor_HS1PumpBRun
HeatingActual.Cor_HS1PumpAStart(0)
HeatingActual.Cor_HS1PumpBStart
HeatingActual.Cor_HS1CV1(0)
HeatingActual.Cor_HS1PID_Output
HeatingActual.Cor_HS1RetPID_Output
HeatingSettings.Cor_HS1PumpDayLimit(0)
HeatingSettings.Cor_HS1PumpNightLimit(0) R,3
HeatingSettings.Cor_PowerLimit_SetPoint
HeatingSettings.Cor_PowerLimitPID_Pgain
HeatingSettings.Cor_PowerLimitPID_Itime
HeatingActual.Cor_PowerLimitPID_Input
HeatingActual.Cor_PowerLimitPID_SetP
HeatingActual.Cor_HS1OptActualStart-
Time(0)
HeatingActual.Cor_HS1RetPID_Input
HeatingActual.Cor_HS1RetPID_Output
HeatingActual.Cor_HS1RetPID_SetP
P100013568
Modbus-
Typ
BACnet
Address
R,3
535
R,4
4
AV,
40004
R,3
17
AV,
30017
R,4
5
AV,
40005
L,2
11
BV,
20011
L,2
12
BV,
20012
L,2
103
L,2
104
R,4
153
R,4
160
AV,
40160
R,4
346
AV,
40346
R,3
521
524
R,3
617
AV,
30617
R,3
620
R,3
621
R,4
353
AV,
40353
R,4
355
AV,
40355
R,4
350
R,4
410
AV,
40410
R,4
413
R,3
731
AV,
30731
Default-
Beschreibung
Wert
0 °C
Parallel transfer of setpointcurve
HS1
Room temperature HS1
21°C
Setpoint room temperature HS1
Return temperature HS1
Is set if running pump HS1 P1A
Is set if running pump HS1 P1B
Start signal pump HS1 P1A
Start signal pump HS1 P1B
Control signal HS1 CV (0-10 V)
Controller output HS1 (0-100%)
Controller output HS1 Return
temp.
(0-100%)
17°C
Outdoor temp for pump stop day
HS1
17°C
Outdoor temp for pump stop night
HS1
Setpoint HS1 power limit
P-band HS1 power limit
I-time HS1 power limit
Controller Input HS1 power limit
(kW)
Controller Setpoint HS1 power
limit (kW)
Start Optimizer, Time until start
HS1
Actual difference between HP and
HS1 return
Controller output HS1 Return
temp (0-100%)
3°C
HS1 Max Delta-T HP/HS
Actual/Setpoint
17/92
