Input/Output
Signalbezeichnung
HeatingSettings.Cor_UDi1
HeatingSettings.Cor_UDi2
HeatingSettings.Cor_UDi3
HeatingSettings.Cor_UDi4
HeatingSettings.Cor_ExpDi(8)
HeatingSettings.Cor_ExpDi(9)
HeatingSettings.Cor_ExpDi(10)
HeatingSettings.Cor_ExpDi(11)
HeatingSettings.Cor_ExpDi(20)
HeatingSettings.Cor_ExpDi(21)
HeatingSettings.Cor_ExpDi(22)
HeatingSettings.Cor_ExpDi(23)
44/92
Modbus-
Typ
BACnet
Adresse
X,4
67
X,4
68
X,4
69
X,4
70
X,4
292
X,4
293
X,4
294
X,4
295
X,4
304
X,4
305
X,4
306
X,4
307
Default-
Beschreibung
Wert
Connected signal on UDI1:
0 = Disable
1 = HS1 PumpA
2 = HS1 PumpB
3 = HS2 PumpA
4 = HS2 PumpB
5 = HS3 PumpA
6 = HS3 PumpB
7 = CS1 PumpA
8 = CS1 PumpB
9 = HW1 Pump
10 = HP1 Pump
11 = Frequency
12 = Expansion Vessel
13 = External Alarm
14 = Boiler Alarm
15 = External Effectlimit
16 = Water Pulse
17 = Energy Pulse
18 = CW1 Pulse
19 = CW2 Pulse
20 = Electric Pulse
21 = CS1 Start
22 = HB1
23 = HB2
24 = HB3
25 = HB4
26 = HB1 Pump
27 = HB2 Pump
28 = HB3 Pump
29 = HB4 Pump
30 = Transport Pump
31 = HB External Stop
32 = Pressure
33 = Extra Circuit Pump
Connected signal on UDI2:
(See signal list for UDI1)
Connected signal on UDI3:
(See signal list for UDI1)
Connected signal on UDI4:
(See signal list for UDI1)
Connected signal on EXP1 DI1:
(See signal list for UDI1)
Connected signal on EXP1 DI2:
(See signal list for UDI1)
Connected signal on EXP1 DI3:
(See signal list for UDI1)
Connected signal on EXP1 DI4:
(See signal list for UDI1)
Connected signal on EXP2 UDI1
(See signal list for UDI1)
Connected signal on EXP2 UDI2
(See signal list for UDI1)
Connected signal on EXP2 UDI3
(See signal list for UDI1)
Connected signal on EXP2 UDI4
(See signal list for UDI1)
flexotron800
P100013568
