flexotron800
Signalbezeichnung
HeatingActual.Cor_HB2ReturnTemp_Output
HeatingActual.Cor_HB3ReturnTemp_Output
HeatingActual.Cor_HB4ReturnTemp_Output
HeatingActual.Cor_HBPID_Output
HeatingSettings.Cor_HB1MinRunTime
HeatingSettings.Cor_HB2MinRunTime
HeatingSettings.Cor_HB3MinRunTime
HeatingSettings.Cor_HB4MinRunTime
HeatingSettings.Cor_HB1MinStopTime
HeatingSettings.Cor_HB2MinStopTime
HeatingSettings.Cor_HB3MinStopTime
HeatingSettings.Cor_HB4MinStopTime
HeatingSettings.Cor_HB1ReturnTempSetP
HeatingSettings.Cor_HB2ReturnTempSetP
HeatingSettings.Cor_HB3ReturnTempSetP
HeatingSettings.Cor_HB4ReturnTempSetP
HeatingSettings.Cor_HBSetPointHSdepending R,3 640
HeatingSettings.Cor_HBHyst
HeatingSettings.Cor_TPStartLimit
HeatingSettings.Cor_TPHyst
HeatingSettings.Cor_HB1SD1
HeatingSettings.Cor_HB2SD1
HeatingSettings.Cor_HB3SD1
P100013568
Typ Modbus- BACnet Default-
Adresse
R,4 390 AV,
40390
R,4 391 AV,
40391
R,4 392 AV,
40392
R,4 393 AV,
40393
I,3 628
I,3 629
I,3 630
I,3 631
I,3 632
I,3 633
I,3 634
I,3 635
R,3 636 AV,
30636
R,3 637 AV,
30637
R,3 638 AV,
30638
R,3 639 AV,
30639
AV,
30640
R,3 641
R,3 642 AV,
30642
R,3 643 AV,
30643
R,3 644 AV,
30644
R,3 645 AV,
30645
R,3 646 AV,
30646
Beschreibung
Wert
Controller output HB2 Return
temp valve (0-100%)
Controller output HB3 Return
temp valve (0-100%)
Controller output HB4 Return
temp valve (0-100%)
Controller output HB (0-100%)
180 Minimum runtime before HB1 is
allowed to stop again.
180 Minimum runtime before HB2 is
allowed to stop again.
180 Minimum runtime before HB3 is
allowed to stop again.
180 Minimum runtime before HB4 is
allowed to stop again.
180 Minimum stoptime before HB1
is allowed to start again.
180 Minimum stoptime before HB2
is allowed to start again.
180 Minimum stoptime before HB3
is allowed to start again.
180 Minimum stoptime before HB4
is allowed to start again.
40 Setpoint return temp. HB1
40 Setpoint return temp. HB2
40 Setpoint return temp. HB3
40 Setpoint return temp. HB4
5 offset (Heating system setpoint
depending)
0,5 Hysteresis for stoping/Starting
Boilers
18 Transport pump start limit
1 Hysteresis for stoping the Trans-
port pump
5 HB1 Switch Difference 1
5 HB2 Switch Difference 1
5 HB3 Switch Difference 1
Actual/Setpoint
