Applying and releasing the brakes

WARNING
Always apply the brakes when a patient is getting on the product or off the product or when the product is not moving.
Injury could result if the product moves while a patient is getting on the product or off the product.
To apply the brakes, push down on the brake (red) side of the brake/steer pedal. Push on the product to make sure that
the brakes work.
To release the brakes, push down on the steer (green) side of the brake/steer pedal.

Raising or lowering the litter

WARNING
• Always put the product in the lowest position with the siderails up and latched when you leave a patient unattended
on the product. Do not leave the product at a higher height.
• Always remove any devices that may be in the way before you raise or lower the litter.
• Do not sit on the end of the product. The product may tip.
• Always keep patient and operator extremities away from siderail spindles when you raise or lower the siderail.
To raise the litter, press down on the pump pedal (A) until you achieve the desired height
To lower the entire litter, press on the center of the uni-lower pedal (B).
To lower the head end of the litter, press down on the side of the uni-lower pedal (B) closest to the head end of the
product.
To lower the foot end of the litter, press down on the side of the uni-lower pedal (B) closest to the foot end of the
product.
Note: The base may be equipped with optional variable descent controls. With variable descent controls, the farther you
press down on the pedal, the faster the litter will lower.
