5. Insert the ink cartridge into the carriage as shown in the diagram.
6. Lower the arms on the carriage to lock the ink cartridge in place.
7. Reverse this procedure to remove the ink cartridge when it is time to be replaced.

Adjusting the Printing Position

You set the horizontal start position by moving the ink carriage in the imprinter unit itself. Move the ink carriage
left or right and align the arrow tab to the appropriate paper width indicated on the imprinter unit. The vertical
start position is set in the scanning interface you are using.
