5.1.13 - Output flow meter
The page shows two flow meters. The first shows the total output flow
delivered by the machine. The second shows a partial count and can be
reset by the user.
The partial count can be reset from this page, by holding down the " - "
button for 2 sec.
5.1.14 - VE: Version display
Hardware and software version with which the appliance is equipped.
5.1.15- FF: Fault log display
Chronological display of the faults that have occurred during system op-
eration.
Under the symbol FF appear two numbers x/y indicating respectively the
ault displayed and the total number of faults present; to the right of these
numbers is an indication of the type of fault displayed.
The + and – keys scroll through the list of faults: pressing the – key goes
back through the log and stops at the oldest fault present, pressing the +
key goes forward in the log and stops at the most recent fault.
The faults are displayed in chronological order starting from the one that
appeared farthest back in time x=1 to the most recent x=y. The maximum
number of faults that can be shown is 64; when that number is reached,
the log starts to overwrite the oldest ones.
This item on the menu displays the list of faults, but does not allow reset.
Reset can be carried out only with the dedicated control from item RF on
the TECHNICAL ASSISTANCE MENU.
The fault log cannot be deleted with a manual reset, by switching off the
appliance, or by resetting the factory values, unless the procedure de-
scribed above has been followed.

5.2 - Monitor Menu

From the main menu, by holding down simultaneously for 2 sec the keys
"SET" and "-" (minus), or using the selection menu and pressing + or -, you
can access the MONITOR MENU.
In this menu, by pressing the MODE key, the following values are dis-
played in sequence.
57
5.2.1 - CT: Display contrast
Adjusts the display contrast.
5.2.2 - BK: Display brightness
Adjusts the backlighting of the display on a scale from 0 to 100.
5.2.3 - TK: Backlight switch-on time
Sets the time that the backlight is lit since the last time a key was pressed.
Values allowed: '0' always off; from 20 sec to 10 min or 'always on'.
When the backlight is off, the first time any key is pressed has the sole ef-
fect of restoring the backlighting.
5.2.4 - LA: Language
Display in one of the following languages:
• Italian
• English
• French
• German
• Spanish
• Dutch
• Swedish
• Turkish
• Slovak
• Romanian
• Russian
5.2.5 - TE: Dissipator temperature display

5.3 - Setpoint Menu

From the main menu, hold down simultaneously the "MODE" and "SET"
keys until "SP" appears on the display (or use the selection menu pressing
+ or -).
The + and – keys allow you respectively to increase and decrease the
plant boosting pressure.
Press SET to leave this menu and return to the main menu.
The range of adjustment is 1-5.5 bar (14-80 psi).
5.3.1 - SP: Setting the setpoint pressure
Pressure at which the system is pressurised.
