Sun Microsystems Sun Fire X4100 Handbuch Seite 228

TABELLE D-7
Pin-Nummer
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
D-10 Sun Fire X4100 und Sun Fire X4200 Server Einrichtungs- und Wartungshandbuch • November 2005
Pin-Belegung des Flex-Kabelanschlusses zur Hauptplatine (Fortsetzung)
Signalname
DVD_DADDR[0]
GND
DVD_DADDR[2]
SAS_DISK1_TX_P
DVD_DCS1_L
SAS_DISK1_TX_N
DVD_DCS3_L
GND
DVD_DASP_L
SAS_DISK3_TX_P
+5V
SAS_DISK3_TX_N
GND
GND
SAS_DISK0_TX_N
+5V
SAS_DISK0_TX_P
+5V
GND
+5V
SAS_DISK2_TX_N
DISK1_FAIL_LED
SAS_DISK2_TX_P
SPINDLE_ID0
GND
DISK0_FAIL_LED
SAS_DISK0_RX_N
DISK3_FAIL_LED
SAS_DISK0_RX_P
DISK2_FAIL_LED
