Replacement parts: PILOT Maxi-HD-K (Material connection)
2 optional: V-air cap for nozzle size
V 11 631 12 054* 0.3 mm to 1.0 mm ø
V 11 631 12 204* 1.2 mm to 1.8 mm ø
V 11 631 12 254* 2.0 mm to 2.5 mm ø
3 optional: Material nozzle
V 11 641 40 . . 3* (for nozzle size 0.3 mm to 2.5 mm ø)
4 not applicable
16 V 11 642 30 . . 3* Material needle (optional)
40 V 11 618 01 000 Gun body
41 V 11 611 03 003 Material connection nipple
42 V 00 101 81 093 Hose grommet
43 V 00 101 12 005 Sleeve nut
Replacement parts: PILOT Maxi-HD-K (Gravity-feed cup)
2 optional: V-air cap for nozzle size
V 11 631 12 054* 0.3 mm to 1.0 mm ø
V 11 631 12 204* 1.2 mm to 1.8 mm ø
V 11 631 12 254* 2.0 mm to 2.5 mm ø
3 optional: Material nozzle
V 11 641 40 . . 3* (for nozzle size 0.3 mm to 2.5 mm ø)
4 not applicable
6 V 11 626 01 000 Gun body
16 V 11 641 30 . . 3* Material needle (optional)
Replacement parts: PILOT Maxi-ND-K (Material connection)
2 optional: V-air cap for nozzle size
V 11 631 12 054* 0.3 mm to 1.0 mm ø
V 11 631 12 204* 1.2 mm to 1.8 mm ø
V 11 631 12 254* 2.0 mm to 2.5 mm ø
3 optional: Material nozzle
V 11 641 40 . . 3* (for nozzle size 0.3 mm to 2.5 mm ø)
4 not applicable
5 V 11 631 04 000 Air distributor ring
16 V 11 642 30 . . 3* Material needle (optional)
26 V 11 631 05 000 Air pipe, complete
40 V 11 620 01 000 Gun body
41 V 11 611 03 003 Material connection nipple
42 V 00 101 81 093 Hose grommet
43 V 00 101 12 005 Sleeve nut
Replacement parts: PILOT Maxi-ND-K (Susp. pressure cup)
2 optional: V-air cap for nozzle size
V 11 631 12 054* 0.3 mm to 1.0 mm ø
V 11 631 12 204* 1.2 mm to 1.8 mm ø
V 11 631 12 254* 2.0 mm to 2.5 mm ø
3 optional: Material nozzle
V 11 641 40 . . 3* (for nozzle size 0.3 mm to 2.5 mm ø)
4 not applicable
5 V 11 631 04 000 Air distributor ring
16 V 11 642 30 . . 3* Material needle (optional)
26 V 11 631 05 000 Air pipe, complete
40 V 11 622 01 000 Gun body
V 66 100 14 096 Reducing valve
V 11 352 73 000 Suspended pressure cup
41 V 11 611 03 003 Material connection nipple
Replacement parts: PILOT Maxi-ND-K (Gravity-feed cup)
2 optional: V-air cap for nozzle size
V 11 631 12 054* 0.3 mm to 1.0 mm ø
V 11 631 12 204* 1.2 mm to 1.8 mm ø
V 11 631 12 254* 2.0 mm to 2.5 mm ø
3 optional: Material nozzle
V 11 641 40 . . 3* (for nozzle size 0.3 mm to 2.5 mm ø)
4 not applicable
5 V 11 631 04 000 Air distributor ring
6 V 11 623 01 000 Gun body
16 V 11 641 30 . . 3* Material needle (optional)
26 V 11 631 05 000 Air pipe, complete
Nozzle sizes available: 0.3 • 0.5 • 0.8 • 1.0 • 1.2 • 1.4 • 1.5 • 1.8 • 2.0 • 2.2 • 2.5 mm ø
V 11 618 02 . . 3
Repair sets
WALTHER supplies repair sets containing all wearing parts for the hand-held spray
guns PILOT Maxi-HD, MD and ND. This parts are shown in boldface print in the list
of the replacement parts.
PILOT Maxi-HD (Gravity feed cup):
PILOT Maxi-HD (Material connection and suction cup):
V 11 626 02 . . 3
PILOT Maxi-HD-K (Material connection):
PILOT Maxi-HD-K (Gravity feed cup):
PILOT Maxi-MD (Gravity feed cup):
PILOT Maxi-MD (Material connection and suspended pressure cup):
V 11 620 02 . . 3
PILOT Maxi-ND (Gravity feed cup):
PILOT Maxi-ND (Material connection and suspended pressure cup):
PILOT Maxi-ND-K (Material connection and suspended pressure cup):
PILOT Maxi-ND-K (Gravity feed cup):

Nozzle Sets

V 11 622 02 . . 3
Nozzle sets consist of air cap, material nozzle and material needle.
PILOT Maxi-HD (Gravity feed cup):
PILOT Maxi-HD (Material connection and suction cup):
PILOT Maxi-HD-K /-ND-K* (Material connect. and susp.pres. cup*):
PILOT Maxi-HD-K /-ND-K (Gravity feed cup):
PILOT Maxi-MD (Gravity feed cup):
V 11 623 02 . . 3
PILOT Maxi-MD (Material connection and suspended pressure cup):
PILOT Maxi-ND (Gravity feed cup):
PILOT Maxi-ND (Material connection and suspended pressure cup:
Nozzle sizes available: 0,3 • 0,5 • 0,8 • 1,0 • 1,2 • 1,4 • 1,5 • 1,8 • 2,0 • 2,2 • 2,5 mm ø
V 16 613 03 . . 3
V 16 614 03 . . 3
V 16 618 02 . . 3
V 16 626 02 . . 3
V 16 615 04 . . 3
V 16 616 04 . . 3
V 16 633 04 . . 3
V 16 634 04 . . 3
V 16 620 02 . . 3
V 16 623 02 . . 3
V 15 613 03 . . 3
V 15 614 03 . . 3
V 15 620 02 . . 3
V 15 623 02 . . 3
V 15 615 04 . . 3
V 15 616 04 . . 3
V 15 633 04 . . 3
V 15 634 04 . . 3
