WALTHER PILOT PILOT Maxi-HD Betriebsanleitung Seite 21

PILOT Maxi-ND / MD
Net weight:
Air caps:
Pressure ranges, medium pressure:
Max. spraying air pressure
Max. input air pressure
Max. material pressure
Pressure ranges, low pressure:
Max. spraying pressure
Max. input air pressure
Max. operating temperature:
Noise level
(measured at approx.
1 m from the spray gun):
Air consumption:
Atomising air pressure
1 bar
2 bar
3 bar
4 bar
5 bar
6 bar
Maxi-ND
Atomising air
Round jet
pressure
in l/min.
1 bar 160
2 bar 210
3 bar 240
4 bar 270
5 bar 310
6 bar 340
Right to effect technical changes reserved.
11
440 g
Low-pressure cap (fillers)
Low-pressure cap (lacquer)
V-air cap (adhesives)
Medium-pressure cap
1.4 bar
3.3 bar
8 bar
0.7 bar
3.5 bar
43 °C
83 dB(A)
Maxi-MD
Round jet Wide jet
in l/min. in l/min.
65 90
100 160
140 210
180 270
215 320
260 370
Maxi-ND-K
Wide jet Round jet Wide jet
in l/min. in l/min. in l/min.
180 180
250 220
330 280
370 310
430 350
490 390
200
270
330
370
430
490
