Cleaning

Caution
Do not use any hard, sharp or pointed objects when cleaning the spray gun. Never
immerse the spray gun in solvent or any other cleaning solution. The functional reliabi-
lity and efficiency of the gun can otherwise not be guaranteed. Clean the Teflon
ted gun body with a soft cloth. WALTHER PILOT is not responsible for any damage
resulting from improper cleaning.
The gun does not need to be dismantled for cleaning.
1. Fill the cleaned material container / gravity-feed cup / syphon -feed cup / suspen-
ded pressure cup or the cleaned pressure tank with a cleaning fluid compatible with
the sprayed material.
2. Operate the spray gun.
3. Do not stop the spray gun until clear cleaning fluid emerges from the nozzle.
The entire system should then be depressurised until the gun is used again. Clean the
spray gun only with cleaning agents which have been recommended by the manufac-
turer of the sprayed material and which do not contain the following constituents:
• halogenated hydrocarbons (e.g. 1,1,1-trichloroethane, methylene chloride, etc.)
• acids and acidic cleaning fluids
• regenerated solvents (so-called cleaning thinners)
• paint removers
The above-mentioned constituents cause chemical reactions on electroplated compo-
nents, resulting in corrosion damage.
Clean the spray gun
• before each change of spraying material
• at least once a week or
• several times a week if required by the spraying medium and depending on the
degree of fouling.
Detailed
Cleaning
1. Disassemble the spray gun
2. Clean the air cap and the material nozzle with a soft brush and cleaning fluid.
3. Clean all other components and the gun body with a soft cloth and cleaning fluid.
4. Coat the following parts with a thin layer of grease:
• needle spring
• all sliding parts and bearing points.
The moving internal parts must be greased at least once a week.
The springs should always be coated with a thin layer of grease. For this, always use
a non-acidic, non-resinogenic grease and a soft brush. Assemble the gun again in
reverse order.
9
10

Disposal of cleaning and servicing substances

Waste spraying media and waste material from cleaning and servicing must be
disposed of in accordance with all applicable local and national regulations.
® Warning
-coa-
Observe the instructions issued by the manufacturers of the spraying and clea-
ning material at all times.The improper disposal of waste material endangers the
health of human beings and animals!
11

Technical data

PILOT Maxi-HD
Net weight:
Air caps*:
Pressure ranges:
Max. input air pressure
Max. material pressure
Max. operating temperature:
Noise level
(measured at approx.
1 m from the spray gun):
Air consumption:
Atomising air
pressure
1 bar
2 bar
3 bar
4 bar
5 bar
6 bar
440 g
Six-hole air cap
V-air cap (adhesives)
*Other air caps available on
request.
8 bar
8 bar
43 °C
85 dB(A)
Maxi-HD
Round jet Wide jet Round jet
in l/min. in l/min. in l/min.
110 250 140
130 330 170
150 410 190
160 460 200
170 510 210
180 560 220
Maxi-HD-K
Wide jet
in l/min.
290
370
450
460
510
560
