Maintenance - Scheppach EB1650 Originalanleitung

Fig. 7
13
Fig. 9
Fig. 10
60
12
3
G
H
Operating the earth auger (Fig. 7)
Before starting the motor, check the following:
Fuel level - the fuel tank should be at least half
–
full
Condition of the fuel lines
–
Outer screw couplings for tight fit
–
The earth auger has to be able to run freely
–
1 Take up a secure and safe position.
2 Hold on to the earth auger with both hands in order
to cushion any impact that may occur.
3 Set the auger down and actuate the throttle control
lever (13).
4 Adjust the power according to the ground conditions
in order to be able to proceed ideally.
5 If the ground condition is ideal, permitting a steady
work speed, using the adjusting screw, you can lock
the throttle control lever (13) (in the centre position)
in order to make your work easier.
Observe national stipulations during work when us-
ing the auger on public property or paths.
Keep adults, children and animals away from the
hazardous area.
Check the working environment for foreign bodies
and remove them.
6 When leaving the auger, the motor must always be
turned off.

Maintenance

For all work on the machine, the spark plug cap and
the spark plug have to be removed (high voltage).
Please adhere to the maintenance schedule
Daily before beginning work
Check fuel tank and fuel lines for tightness
Check mounting parts, exhaust cover, air filter cover,
oil, position of the auger and functioning of the operat-
ing elements
After 20 operating hours
Clean air filter and check spark plug
After 100 operating hours
Clean fuel tank and replace spark plug
After 300 operating hours
Replace air filter
Important notice in the event of repairs:
When sending earth augers to be repaired, please note
that, for safety reasons, they must be delivered to the
service station free from oil and petrol.
Warning! No smoking and no open fire.
Risk of explosion
Air filter, Fig. 9-10
Regular cleaning of the air filter prevents carburettor
malfunctions.
