Sectional drawings and spare parts

Connector 4 /
vent hole
for control
function 1
A
Connector 2 /
vent hole
for control
function 2
Leak detection
hole
a
4
30
b
c
14
d
512
Item Name
1 Valve body
4 Gasket
14 Seat seal
30 Gasket
A Actuator
a Union nut
b Spindle
c Valve plug
d Retaining nut
GEMÜ 512 with
Order description
K 500...
}
512...SVS...
9512
-
-
-
-
30 / 36
PTFE seat seal
Mounting parts
Actuator flange
Valve body
flange
1
