FP FPi 2500 Betriebsanleitung Seite 78

Paper quality
Flap shoulder angle
Flaptypes
Adhesive type
Seamtypes
Window size
Remarks
Minimum envelope weight: 75 g/m2
Maximum envelope weight: 120 g/m2
Between 45° to 85°
Wallet
Mailpoint
Trapezoid
Commercial
Note: Open flap envelopes are not suppor-
ted
Gum
Side seam,
Diagonal seam,
Single side seam.
Maximum window width: Envelope width
minus 30 mm
Maximum window height: 50% of the envel-
ope height
Maximum 2 mm of the window is not glued
Minimum windows distance to envelopside:
15 mm.
Mimimum windows distance to enveloptop:
15 mm to the envelope creaseline
Maximum set thickness is 2 mm (0.08")
Maximum insert specifications are based
on single sheets. When multiples are
handled, more room inside the envelope is
needed depending on the application.
In general more space between the set
width and the envelope width will improve
the performance of the system.
The specification of the paper handling
equipment is often wider than that of the
envelopes and documents handled.
We recommend that materials to be
handled are stored at a temperature of 20°C
(68°F) with a relative humidity factor of 50%.
If difference in temperature occurs between
store room and mailing area, the material
has to be stored near the system at least
24 hours before use.
