4. Release back support C.
5. Move the side guides towards the envelopes. The play between the side guides and
the envelopes should be about 0.5 mm (0.02'').
6. Extend supports B when you work with wide envelopes.
7. Place a stack of envelopes in the hopper (see figure).
8. Set the side guides of the stacker according to the envelope width. Rotate B to move
the side guides. Use the indicators C on the fingers to determine the side guide position.
If necessary, remove extensions D.
Use an envelope to measure the play. If an envelope fits between
the envelopes and the side guides, the play is correct.
Refer to the specifications for the maximum amount
of envelopes you can load into the feeder.
