Loading Documents

The table below shows how to load documents depending on the fold type, and the optional
Enclosure and BRE feeders. See the job information on the touch screen.
2
no fold
V-fold
C-fold
double V-fold
Z-fold
To load documents:
1. Rotate thumb wheel A to move the side guides apart on the feeder.
12
one document
feeder linking
Address carrier.
Address carrier
Face up and
in upper feeder.
leading
Face up and
leading.
Address carrier.
Address carrier.
Face down and
Face down and
trailing.
trailing.
document + en-
document +
closure
BRE/insert
Address carrier
Address carrier
in upper feeder.
in upper feeder.
Face up and
Face up and
leading.
leading.
Address carrier
Address carrier
in lower feeder.
in upper feeder.
Face down and
Face down and
trailing.
trailing.
