Loading BREs (option)

You can use the optional BRE feeder for small insert cards or BREs.
To load BREs:
2
1. Rotate thumb wheel A to move the side guides apart.
2. Pull back support B.
3. Put a small stack of documents or BREs between the side guides.
4. Release back support B.
5. Move the side guides toward the documents or BREs. The play between the side
guides and the documents should be about 0.5 mm (0.02'').
14
Use an envelope to measure the play. If an envelope fits between
the documents and the side guides, the play is correct.
