Parts description
Q
Figure A:
Battery pack compartment
1
Rear handle
2
On / off switch
3
4
Lock-off button
5
Rear safeguard
6
Loop
7
Clip
8
Harness
9
Gripping surface
10
Pole
11
Locking lever
12
Pole extension
13
Locking sleeve
14
Unlock button (angle adjustment)
15
Air vents
16
Cutting device (blade)
17
Blade cover
Figure B:
Battery pack
18
Battery charging level button
19
Release button
20
Battery level indication light
21
Figure C:
Rapid charger
22
Charger status LED – Green
23
Charger status LED – Red
24
Scope of delivery
Q
1 Cordless Long-Reach Hedge Trimmer
FALHS 40-Li A1
1 Blade cover
1 Harness (pre-assembled)
1 Battery pack FAP 40 A1
1 Rapid battery charger FLG 40 A1
1 Operating instructions
Technical data
Q
Cordless Long-Reach
Hedge Trimmer:
Rated voltage:
Rated no load speed n
0
Effective cutting length:
Cutting capacity /
blade gap:
Weight (incl. accessories): 5.8 kg
Battery pack:
Type:
Rated voltage:
Capacity:
Number of cells:
Rapid battery charger: FLG 40 A1
INPUT:
Rated voltage, frequency: 200 – 240 V ~ ,
Power consumption:
OUTPUT:
Rated voltage:
Charging current:
Charging time:
Protection class:
Noise emission value
Noise measurement value determined in
accordance with EN 60745-2-15 and
EN ISO 10517. The A-rated noise level of the
power tool is typically as follows:
Sound pressure level L
pA
Uncertainty K
:
pA
Sound power level L
:
WA
Guaranteed sound power
level L
:
WA
(according to 2000/14/EC amended by
2005/88/EC)
Vibration emission value
Total vibration values (vector total of three
directions) determined in accordance with
EN 60745-2-15 and EN ISO 10517:
(rear handle)
Hand / arm vibration a
(gripping surface)
Hand / arm vibration a
Uncertainty K:
FALHS 40-Li A1
36 V
,
max. 40 V
:
2500 min
-1
approx. 430 mm
18 mm
FAP 40 A1
Lithium ion
36 V
,
max. 40 V
2.5 Ah (90 Wh)
10
50/60 Hz
160 W
36 V
3.6 A
approx. 60 min
II /
:
80.5 dB(A)
3 dB
92.4 dB(A)
100 dB(A)
:
< 2.5 m/s
2
h
:
< 2.5 m/s
2
h
1.5 m/s
2
GB
7
