1.18 Rudder to aileron mix

GB
This function can be used to counteract undesirable
roll of aircraft with rudders and ailerons. This
happens with the rudder input, when it is crabbing .
It is the pre-programmed mix which mixes the
aileron with the rudder operation
This setup can modify the master channel' s rate, and
the default value is 10%.
If the aircraft does not have the aileron or the rudder,
these two function icons will not be displayed. This
function can be set up in each of five conditions.
Select the desired low side or high side to set the rate
and move the wheel to modify the corresponding
value after activating this function. This function can
be assigned to a switch (SwA~SwH, LSw).
As shown in pictures 21.8 and 21 .9: The low side rate
Pic. 21.8 Pic. 21.9
is set to 20% and the high side rate to 20%. Move the
rudder stick to the far left, and the corresponding
channels are displayed as shown in picture 21.8.
Move the rudder stick to the far right, and the
corresponding channels are displayed as shown in
picture 21.9.
Pic 21.8 Rudder stick to the far left
Pic 21.9 Rudder stick to the far right
