1.31 Trainer mode

This function allows you to connect 2 transmitters
together using a dedicated cable (see page 53,
No.14 optional) connected to the back interface.
Once enabled, switching on the selected trainer
switch will set up the remote as the instructor and
use the trainer transmitter to control the model.
Use dedicated cable to connect two transmitters
and touching trainer mode to activate function. The
trainer transmitter can control 8 channels of learner
model, and you can select stick or knob, basic
function, output channel or none. Select display
servos function, push down SwE and hold it learner
model's channels will display in real time.
Activated trainer mode function, setting Channel
1 to aileron function, channel 5-8 is None. Learner
model's channels will display. As shown in picture
21.32.

1.32 Display Servos

This function is to display model channel output and
automatically test all output channels This function
displays in real time the position of the 10 servos.
The test button lets the servos move slowly between
their respective end points.
This allows testing of the consistency of the mecha-
nics of the model.
CARSON Reflex Stick Ultimate Touch 500501002
Pic. 21.31 Pic. 21.32
Display servos of trainer
transmitter.
Pic. 21.33
