1.5 Main menu

Settings
The main menu can be accessed by touching the
settings icon at the bottom of the main screen.
The main menu is organized in horizontal pages.
Each page contains up to 12 icons representing 12
different functions.
The white balls in the bottom tray indicate which
menu page is displayed. The big white ball
represents the currently displayed page.
Top Tray
(System Status)
The top tray of the screen constantly displays the
main status of the whole system.
Displays the signal strength received by the
1
vehicle. The strongest signal is represented
with five bars. When the signal strength is
lower or equal to two bars, an audible alarm
rings.
Displays the number and the name of the
2
currently selected model.
Charging
Charging complete
Receiver disconnected
Reveiver battery full charged
CARSON Reflex Stick Ultimate Touch 500501002
Main menu Back
Page 1
Main menu Back
Page 2
• To display the next page, touch the current page
anywhere on its right part and slide it to the left.
• To display the previous page, touch the current
page anywhere on its left part and slide it to the
right.
• To enter a function, simply touch its corresponding
icon.
• To return to the main screen, touch the back
button in the bottom tray.
1 2
3 Displays the status of the remote control
battery. If the voltage is too low, an audible
alarm rings and this symbol blinks.
Displays the status of the receiver battery. If
4
the voltage is too low, an audible alarm rings
and this symbol blinks. See further how to set
up the receiver battery alarm voltage.
No voltage signal of receiver
Full charged
Low voltage, charging required
Main menu Back
Page 3
3 4
