As shown in the picture 21.5, VrA is selected. The exponential function
GB
is activated. The selected parameter is rate and is set to its maximum
value. The horizontal dotted line shows the VrA 60 on the left side. But
the horizontal dotted line indicates that the resulting channel output is at
the position between 20 and 40 under the middle position showing the
efficiency of the exponential function.

1.17 Aileron to rudder mix

The aileron to rudder automatically creates a
coordinated turn for the aircraft with aileron and
rudder. lt is the pre-programmed mix which controls
the Rudders with the aileron operation and can
modify the master channels rate, which is 10% by
default.
lf the aircraft does not have the aileron or the rudder
these two function icons will not be displayed.
This function can be set in five Conditions.
Select the desired low side or high side to set the rate
and move the wheel to modify the corresponding
values after activating this function. This function
can be assigned to a switch (SwA~SwH~ LSW).
For this example: The low side rate is set to 20% and
the high side rate to 20% - Move the rudder stick
to the far left, and the corresponding channels are Pic. 21.6 Pic. 21.7
displayed as shown in picture 21.6. Move the aileron
stick to the far right, and the corresponding channels
are displayed as shown in picture 21.7.
Pic 21.6 Aileron to the far left
Pic 21.7 Aileron to the far right
CARSON Reflex Stick Ultimate Touch 500501002 97
