POWERING ON THE RC SYSTEM

1. Connect all the components as described in the operating
instructions.
2. Switch on the transmitter at the power button.
3. Connect the RX battery to the receiver or the driving battery to
the ESC.
4. The red LED on the receiver will light up and confirm the receipt
of a correct signal.
5. If the error rate is less than 5%, the receiver signal is stable.
6. The RC system can now be used.
To switch off, proceed in reverse order. Switch off the receiver first,
then the transmitter.

MENU NAVIGATION

Main screen

Receiver sensor´s state
Throttle curve
Engine cut
Throttle idle
Boat mode
Downloaded from www.Manualslib.com
Model name
Receiver signal
feedback
ABS
TH trim state
Help icon
manuals search engine
Power switch
On/Off
LED
Transmitter battery
Receiver battery
Break mixing
Mixes
Race timer
Turn sound
Steering channel state
Throttle channel state
3 channel state
4 channel state
Setting trim state
Settings icon
