Operating instructions

10 Accessories

Hygienic connection adapter
Adapters may only be screwed on once. The torque for the connection adapter should be at least 15
Nm and no more than 25 Nm. Repeated opening can damage the gasket and therefore harm the
hygienic properties. The available adapters for hygienic applications are suitable for the LFP basic
device with threaded connection G ¾ A. Process connection gaskets are to be provided by the custo-
mer.
Flange
Brief description
Hygienic process
connection adapter
for LFP with G 3/4
Hygienic adapter for
LFP with G 3/4" and
3-A housing
Coaxial tubes
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube G 3/4, material 1.4571, for probe length 200 mm
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube 3/4" NPT, material 1.4571, for probe length 200 mm
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube G 3/4, material 1.4571, for probe length 300 mm
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube 3/4" NPT, material 1.4571, for probe length 300 mm
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube G 3/4, material 1.4571, for probe length 400 mm
Coaxial tube for LFP with G 3/4 process connection, process connection
of coaxial tube 3/4" NPT, material 1.4571, for probe length 400 mm
50 8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without notice
10 Accessories
Process connection
Coupling (DIN 11864-1) DN 25 form
A with union nut
Flange (DIN 11864-2) DN 25 form A
Clamp (DIN 11864-3) DN 25 form A
Conical coupling (DIN 11851) DN 25
with union nut
Conical coupling (DIN 11851) DN 40
with union nut
Conical coupling (DIN 11851) DN 50
with union nut
Tri-Clamp 1'' and 1 ½''
Tri-Clamp 2''
Tri-Clamp 1" and 1 ½'' with leakage
indication port according to 3-A
guidelines
Brief description
Model name
BEF-HA-641D25-LFP1
BEF-HA-642D25-LFP1
BEF-HA-643D25-LFP1
BEF-HA-851D25-LFP1
BEF-HA-851D40-LFP1
BEF-HA-851D50-LFP1
BEF-HA-TCLI10-LFP1
BEF-HA-TCLI20-LFP1
BEF-HA-TCLI10-LFP3
Type
LFPCT-0200G1
LFPCT-0200N1
LFPCT-0300G1
LFPCT-0300N1
LFPCT-0400G1
LFPCT-0400N1
LFP
Part No.
2058795
2058823
2058821
2058138
2058139
2058141
2058808
2058824
2058851
Part no.
2068141
2068165
2068142
2068166
2068143
2068167
