LFP
16 Vendor Name
17 Vendor Text
18 Produkt Name
19 Product ID
21 Serial Number
22 Hardware
Revision
23 Firmware Re-
vision
24 Application
Specific
Name
SICK specific
Index Name
(decimal)
64 SP1
65 RP1
66 OUT1
68 SP2_FH2
69 RP2_FL2
8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without
6 Operation
8 x 8 Bit R
8 x 8 Bit R
8 x 8 Bit R
8 x 8 Bit R
8 x 8 Bit R
8 x 8 Bit R
8 x 8 Bit R
16 x 8 Bit R/W
Format Access
16 Bit R / W
unsigned
16 Bit R / W
unsigned
8 Bit unsi- R / W
gned
16 Bit R / W
unsigned
16 Bit R / W
unsigned
SICK AG Name of the manufacturer
http://www. URL of the homepage of the
sick.com manufacturer
LFP Name of the device
String IO link identification number for
the IODD
String Serial number of the
device
String Revision of the hardware of the
LFP
e.g. v 1.0
String Revision of the software of the
LFP
e.g. v 1.0
String (16 cha- Measuring point designation
racters) Can be freely defined
by the customer
Value
Switching point Q1
Reset switching point Q1
0 Normally Switch-over
open - free normally closed / normally open
hysteresis
1 Normally
closed - free
hysteresis
Switching point Q2 in switching
operation.
Middle of the upper edge of the
window in window operation. 1)
Reset switching point Q2 in swit-
ching operation.
Middle of the lower edge of the
window in window operation. 1)
EN
Operating instructions
Description
41
