SICK LFP Inox Betriebsanleitung Seite 42

EN
Operating instructions
Index Name
(decimal)
Index Name
(decimal)
70 OUT2
71 Q2Type
72 QALow
73 QAHigh
1) Limited setting
42 8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without notice
6 Operation
Format Access
Format Access
8 Bit unsi- R / W
gned
8 Bit unsi- R / W
gned
16 Bit R / W
unsigned
16 Bit R / W
unsigned
Value
Value
0 Normally Switch-over
open - free normally closed / normally open.
hysteresis 1)
1 Normally
closed - free
hysteresis
2 Normally
open - window
function
3 Normally
closed - win-
dow function
4 Error sig-
nal, Normally
Open
5 Error sig-
nal, Normally
Closed
0 PNP Determination of the type Q2. 1)
1 NPN
2 Drive
Lower signal point of the
analog output in
millimeters at the end of the
probe.
The analog output displays for
QAPOL = 0 4 mA or 0 V for this
level. For QAPOL = 1, the analog
output displays 20 mA or 10 V.
Upper signal point of the
analog output in
millimeters at the process
connection.
The analog output displays for
QAPOL = 0 20mA or 10V for this
level. For QAPOL = 1, the analog
output displays 4 mA or 0 V.
LFP
Description
Description
