Operating instructions
126 System
Monitor
127 Display Text
128 Simulate
Measured
Value
129 Level
44 8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without notice
6 Operation
16 bit R
unsigned
8 x 8Bit R
8 Bit unsi- R/W
gned
16 Bit R/W
unsigned
Record System diagnosis flags
Bit 0 Internal warning
Bit 1 Q1 short circuit
Bit 2 Q2 short circuit
Bit 3 QA overload
Bit 4 QA current cannot be set or
excess temperature
Bit 5 Supply voltage
insufficient for IO link
Bit 6 Supply voltage insufficient for Q1
and Q2
Bit 7 Supply voltage for QA insufficient
Bit 8 Temperature of the electronics
too high
Bit 9 Temperature of the display too
high
Bit 10 Measurement poor or conspicu-
ous (warning)
Bit 11 Measurement not possible
Bit 12 Echo curve invalid (measure-
ment not possible)
Bit 13 Device not adapted to the tank
(AutoCal still has to be called up)
Bit 14 Other (unknown) fault
Bit 15 Reserved (= 0)
String Current display on the display
e.g. 0 mm or 0%
0 Normal This parameter is volatile. That
measuring means normal measuring opera-
operation tion will be started again in any
case after the LFP is reset.
1 Simulation
operation
Read
Current level in millimeters
Write
If Simulate-Measured-Level=1 is
set, the measured level can be
simulated by writing.
LFP
