LFP
System commands
130 Restore Factory Settings
160 Store Echo Curve in
Device
161 Set Default Setpoints
163 AutoCalibrate

7 Factory setting

Parameter Factory setting
SP1 80% of the probe length measured from the end of the probe
RP1 5 mm below SP1
OU1 Q1_Hno
SimQ1 Q1Norm
SP2 20% of the probe length measured from the end of the probe
RP2 5 mm below SP2
QAHigh 50 mm below probe begin
QALOW 10 mm above probe end
QAPOL QA_Nrm
QATYP Auto
QAFAIL 3,5mA
SimCur SimOff
SimVol SimOff
DspVal Distan
Filter Off
SimLev SimOff
EchoGn 200 %
8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without
7 Factory setting
Resets all SPDUs back to factory settings.
Save of the current echo curve in the device. The echo curve
can be read out again and analyzed by specialists at SICK AG.
If the memory space reserved for this function is full, then the
function will be ignored and no new curves will be saved.
Sets all switching and analog operation characteristic values
to standard values according to the factory setting.
This function is described in chapter 6.1 commissioning
procedure.
EN
Operating instructions
45
