LFP
Parameter
AutCal
Q1MENU, Q2-WHG
SP1/SP2
RP1/RP2
OU1
SimQ1
QAMENU
QAHIGH
QALOW
QAPOL
QATYP
QAFAIL
SimCur
SimVol
DspVal
Distan
8014638/ZQ14/2017-08-25 © SICK AG • Level sensors • Germany • Subject to change without
6 Operation
Description
Activation of the container calibration
Menu switching output 1, Menu switching output 2 according to WHG:
normally closed and Push-Pull fixed setting.Q2-WHG-menu is password
protected.
Switching point switching output 1/2 (SP1 > RP1) and (SP2 > RP2)
Reset point switching output 1/2
Switching function, switching output 1
Hno = hysteresis function, normally open
Hnc = hysteresis function, normally closed
Simulation of the switch outputs 1
Q1Off = switching output off
Q1Norm = switching output in measuring mode
O1On = switching output is active
The simulation will automatically shut off when voltage reset comes.
Menu analog output
Input of the filling level in mm for 20 mA/10 V signal (QAHIGH > QALOW)
Input of the filling level in mm for 4 mA/0 V signal
The analog output signal can be inverted
QA-Nrm = analog output signal as configured
QA-Inv = analog output signal is inverted:
QAHigh 4 mA/0 V and QALow 20 mA/10 V
Setting of the output signal
4-20 mA
0-10 V
Auto ? = automatic signal recognition based on the available burden
For the interrogation of the menu, either 4-20 mA or 0-10 V will be shown.
Auto V = Qa is operating with voltage output 0...10 V
Auto A = Qa is operating with current output 4...20 mA
Output behavior after NE43 for malfunction (function only available if it is
also selected under QATYP of the current output)
3.5 mA = analog current output is set to 3.5 mA in the event of malfunction
21.5 mA = analog current output is set to 21.5 mA in the event of malfunc-
tion
Current values can be simulated (function only available if it was selected
under QATYP of the current output)
The simulation will automatically shut off when voltage reset comes.
Voltage values can be simulated (function only available if it was selected
under QATYP of the voltage output)
The simulation will automatically shut off when voltage reset comes.
Setting of the display
The display shows the distance in mm in relation to the end of the probe.
The switching status of Q1 and Q2 is desplayed above the measurememnt unit.
