4 CONFIGURATION
«EXT. [T] Option
In this option, the user can check the pulse duration being sent to the 8035 Batch controller.
ENTER
EXT.ACT.
RELAY 1 ENTER

4.5.2. Check on operation of relays

This option allows the operator to check for correct operation of the relays by using the
keypad to energise the relays.
RELAY 1
ENTER
RELAY 2
ENTER
FREQUENC
4.5.3. Frequency readout
Readout of paddlewheel rotation frequency. To clear the display and proceed to the next
option, press the ENTER key.
ENTER
FREQUENC
END ENTER
Note: After the display of the «FREQUENC» prompt, pressing the ENTER key will
energise Relay 1 (to open the valve).
0.00 SEC
Start of pulse
REL OFF
REL ON
REL OFF
REL ON
15.25 HZ
E-30-
BATCH CONTROLLER 8035
. . . . SEC 5.35 SEC
End of pulse
ENTER
ENTER
