4 CONFIGURATION

4.3 Main menu

Within the main menu, following readouts are available:
BATCH M
BATCH A
0......9
24563 L
456 L.
The following sub-routines describe the various dosing options together with the prompts
displayed within the main menu. The GREY CHARACTERS are flashing when displayed.
4.3.1.Dosing in manual mode»LOC.MEM» or «MEM+MANU» Options
Generation of a volume previously entered from the keypad.
ENTER
BATCH M
* You can also start the dosage using
the "Start/Pause" binary data input (see
4.2.4).
The volume must be greater than 6 pulses generated by the paddle-wheel. The entry of a
zero volume forces a return to the «BATCH M» option.
The «ALARM» prompt during a dosing operation signifies a dosing problem (see § 5.1).
During the measure of the selected volume, displaying the flow rate, pause, reset or
stop the dosing operation. (see § 4.3.4.; § 4.3.5.) are still possible.
Dosing in manual mode (see § 4.3.1.).
Only available if the «LOC.MEM» or the «MEM+MANU» Options
have been selected within the Calibration menu (see § 4.4)
Dosing in automatic mode (see § 4.3.2.).
Only available if the «LOC.MEM» or the «MEM+MANU» have
been selected within the Calibration menu (see § 4.4)
Main counter using the selected measurement unit (see
Calibration menu). Zero setting within the Calibration menu.
Daily counter using the same measurement unit as the main
counter. A decimal point after the unit differentiates it from the
main counter. Zero setting by simultaneously pressing the two
keys for 3 seconds.
0......9
00000 L
Entering of
volume
0......9
ENTER
00100 L
E-18-
BATCH CONTROLLER 8035
*
ENTER
OK Y/N
ENTER
OK Y/N
Countdown of
volume to 0
00100 L
