16. Installation of the pH pump (only available in scalable version with pH Kit)
(A)
(B)
EN
(C)
(E)
pH Pump
(D)
Pump fixing screw x4 (torx10 3x8 mm)
(F)
(B)
(A)
1. Remove screws under the outer frame (A).
2. Remove outer frame (A)
3. Remove the connection cover fixing screws (B) on the front of the unit.
4. Pull the cover (B) out to give access to fuse pump and connections.
5. Take the pH pump and screws included in the pH Kit (C)
6. Place the pH pump into the compartment (D) and tighten screws
7. Insert the pH pump cable through hole (E)
8. Connect the pH pump cable to connector (F)
9. Fit the junction box cover and fixing screws (B)
10. Fit the front cover (A) and secure by pressing both edges simultaneously.
