Digital In/Out

AES50 SuperMac networking @ 48 or 44.1 kHz, 24-bit PCM
AES50 SuperMac cable length, CAT5 shielded**
ULTRANET networking @ 48 or 44.1 kHz, 22-bit PCM
ULTRANET cable length, CAT5 shielded
ULTRANET phantom power for P16-M personal mixers
Power
Switch-mode autorange power supply
Power consumption
Physical
Standard operating temperature range
Dimensions
Weight
* Incl. all channel and bus processing, excl. insert effects and line delays
** Klark Teknik NCAT5E-50M recommended
NOTE: Please verify that your specific AES50 connections provide stable operation prior to using the products in a live performance or recording situation.
The maximum distance for AES50 CAT5 connections is 100 m / 330 ft. Please consider using shorter connections where possible for gaining safety margin.
Combining 2 or more cables with extension connectors can reduce the reliability and maximum distance between AES50 products. Unshielded (UTP) cable
may work well for many applications, but entails an additional risk for ESD issues. We guarantee, that all our products will perform as specified with 50 m of
Klark Teknik NCAT5E-50M, and we recommend using cable of similar quality, only. Klark Teknik also offers the very cost-effective DN9610 AES50 Repeater or
DN9620 AES50 Extender for situations where extremely long cable runs are required.
Quick Start Guide
2 x 48 channels, bidirectional
Up to 100 m
1 x 16 channels, unidirectional
Up to 75 m
2 powered outputs
100-240 V (50/60 Hz)
45 W 35 W
5°C – 45°C 5°C – 45°C
(41°F – 113°F)
(41°F – 113°F)
333 x 149 x 140 mm 333 x 149 x 95 mm
(13.1 x 5.9 x 5.5") (13.1 x 5.9 x 3.7")
3.2 kg (7.1 lbs) 2.5 kg (5.5 lbs)
