Heaty Racun 300 Advanced Plus | Operation
5

Operation

In the following section you will find instructions on how to operate the device.
NOTE
controls
The controls referred to in the text are explained in section "3 Device de-
scription" on page 17.

5.1 Make settings in the control system

The touch display (see "3.7 Touch display" on page 20) gives you access to the
control of the device. In the control menu you can make the following settings and
activate or deactivate functions:

5.1.1 Starting the system

The System ON function starts or stops the device regardless of the operating
mode.
30

5.1.2 Filling the system

All active modes are highlighted in green. The information field (marked in red)
shows the current status of the device.
If the pump is running, it is highlighted in green. 3-way valve: If the right triangle is
is red, only filtration is active. If the upper triangle is red, the water is additionally
treated via the cartridge. 2-way valve: If the symbol is red, the make-up is closed.
make-up is closed. If the symbol is green, the make-up is open.
Operation | Heaty Racun 300 Advanced Plus
31
