Technical data
Cordless Drill Driver Set
...................................... PBSPA 12 C3
Rated voltage U ...................... 12 V ⎓
Weight with battery (12 V, 2 Ah)
...............................................≈0.95 kg
No-load rotation speed n
– 1st gear ........................0–460 min
– 2nd gear .....................0–1750 min
Max. torque ..............................35 Nm
Chuck capacity .................0.8–10 mm
Max. drilling diameter
– wood .................................... 19 mm
– metal .....................................10 mm
Sound pressure level (L
...............................79.8 dB; K
Sound power level (L
..............................87.8 dB; K
Vibration (a ) . ≤2.5 m/s²; K=1.5 m/s²
h;D
Battery .......................................Li-Ion
Temperature ............................ ≤50 °C
– Charging ........................... 4 – 40 °C
– Operation ......................−20 – 50 °C
– Storage ............................. 0 – 45 °C
Levels of noise and vibration were de-
termined according to the standards
and regulations in the declaration of
conformity.
The specified total vibration value and
the stated noise emission value have
been measured according to a stand-
ardised test method and can be used
to compare one power tool with an-
other. The specified total vibration
value and the stated specified noise
emission value can also be used for a
provisional assessment of the load.
0
−1
−1
)
pA
=5 dB
pA
)
WA
=5 dB
WA
WARNING! The vibration and
noise emissions may deviate from
the specified values during actual
use of the power tool, depending on
how the power tool is being used. Try
to keep the exposure to vibrations
as low as possible. An example of a
measure to reduce vibration expos-
ure is limiting the working hours. All
parts of the operating cycle have to
be considered while doing so (for ex-
ample, times when the power tool
is switched off and times when it is
switched on but running without any
load).
Charging time
The device is part of the
X 12 V TEAM series and can be
operated with batteries of the
X 12 V TEAM series. Batteries of
the X 12 V TEAM series may only
be charged using chargers of the
X 12 V TEAM series.
We recommend that you operate this
appliance with the following batter-
ies only: PAPK 12 A3, PAPK 12 A4,
PAPK 12 B3, PAPK 12 B4,
PAPK 12 D1, PAPK 12 D2
We recommend charging these
batteries with the following char-
gers: PLGK 12 A2, PLGK 12 A3,
PLGK 12 B2, PDSLG 12 A1,
PDSLG 12 A2
Rechargeable battery and charger
technical data: See separate manual.
The charging time is influenced by
factors such as the temperature of
the environment and the battery, as
well as the mains voltage applied,
and may therefore deviate from the
specified values.
