machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
The device is part of the
X 12 V TEAM series and can be
operated with batteries of the
X 12 V TEAM series. Batteries of
the X 12 V TEAM series may only
be charged using chargers of the
X 12 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Drill Driver Set
• Storage bag
• Accessories in storage box
• 7× wood-Drill
(3, 4, 5, 6, 7, 8, 10 mm)
• 7× metal-Drill
(2, 3, 4, 5, 6, 7, 8 mm)
• 16× Screw bit 25 mm
PH1, 2× PH2, PH3
PZ1, 2× PZ2, PZ3
T10, T15, 2× T20, T25, T27,
T30, T40
• 8× Screw bit 50 mm
PH2
PZ2
T10, T15, T20, T25, T30, T40
• Bit holder 60 mm
22
• Translation of the original instruc-
tions
• Rechargeable battery and charger
with instruction manual
Overview
The illustrations for the
device can be found on
the front fold-out page.
1 Keyless chuck
2 Torque adjustment ring
3 Gear selector switch
4 Direction of rotation switch
5 Battery release
6 Battery
7 Handle (Insulated gripping sur-
face)
8 On/Off switch
9 Charge level indicator
10 LED work light
11 Drill chuck aperture
12 Bit holder
13 Screw bit
14 metal-Drill
15 wood-Drill
16 Storage bag
17 Charger
Fig. C
18 Bit holder
19 Chuck ring
Description of functions
The drill driver is equipped with a slip
clutch that decouples the drive from
the spindle when a preselected max-
imum torque is reached.
Please refer to the descriptions below
for information on how the operating
elements work.
