EN
3
2
4
5
1
1. Current knob position (red indicator)
2. Mixing only
3. Stop
4. Cooling only
5. Making ice cream
1 2
1. Left container function knob
2. Right container function knob
After plugging in, turn the knob to select the operating
mode, including: ICE CREAM, COOLING ONLY and MIXING
ONLY. After you finish making ice cream, select the STOP
mode.
3.2. PREPARING FOR USE
APPLIANCE LOCATION
The temperature of environment must not be higher than
40°C and the relative humidity should be less than 85%.
Ensure good ventilation in the room in which the device is
being used. There should be at least 8 cm distance between
each side of the device and the wall or other objects. Keep
the product away from hot surfaces. The device should
always be used when positioned on an even, stable,
clean, fireproof and dry surface, and be out of the reach
of children and persons with limited mental and sensory
functions. Position the device such that you always have
access to the power plug. The power cord connected to
the appliance must be properly grounded and correspond
to the technical details on the product label.
Always place the ice cream maker in an upright position
on a flat surface for the built-in compressor to provide
the best performance. Before first use, disassemble all
parts and wash those that will come into contact with
food, i.e. a fixed bowl, a removable bowl, a mixing knife,
a transparent lid, a filling lid, a measuring cup and a spoon.
Make sure the power cord is disconnected! Connect the
device plug to a suitable power supply.
10
3.3. DEVICE USE
3.3.1. PREPARATION OF ICE CREAM
A. Prepare the ingredients according to your own recipe
or from the recipes in this manual (see point 3.3.2).
CAUTION: There is no need to pre-freeze the bowl
as this device has a built-in compressor that freezes
the ingredients in the recipe while it is running, thus
ensuring greater efficiency.
CAUTION: The initial temperature of the ingredients is
25 ± 5°C. Do not put ingredients in the freezer for pre-
freezing as the blender blade will easily get jammed
before your ice cream is ready.
B. Pour the prepared ingredients and warm water into
a removable bowl, then mix evenly.
CAUTION: To avoid overfilling, make sure that the
ingredients do not exceed 60 % of the capacity of
the removable bowl (ice cream volume will increase
during preparation).
C. Insert the removable bowl into the device and gently
rotate the bowl to fit the fixed bowl.
D. Place the mixing blade in the removable bowl (take
care that the bottom hole in the blade aligns well with
the motor axis). Then put the transparent lid on the
device.
E. Set the appropriate operating mode: ICE CREAM.
Stir until thickened, i.e. approx. 30–60 minutes. The
working time depends on the ingredients used.
F. After shaping the ice cream, turn off the device first,
then pull out the removable bowl. Make sure that the
device is not operating for more than 80 minutes to
prevent condensation.
Rev. 28.05.2024
3.3.2. BASIC RECIPES
A. Vanilla ice cream (8 servings of half a glass: 1 glass of
full-fat milk, half a glass of powdered sugar, a glass
and half of well-chilled heavy cream, 1–2 teaspoons
of vanilla extract for taste). Mix the ingredients until
a homogeneous mass without lumps is achieved.
Pour the prepared mass into a bowl and mix until
thickened, about 30–40 minutes.
B. Chocolate ice cream (8 servings of half a glass: 1 glass
of full-fat milk, half a glass of powdered sugar, 240 g
of dark or semi-sweet chocolate divided into pieces,
1 glass of well-chilled heavy cream, 1 teaspoon of
vanilla extract for taste). Boil the milk. Use a blender
or a mixer to crush the chocolate. Add sugar and
hot milk. Mix until smooth. Move to a bowl to cool.
When the mass has cooled down, add heavy cream
and vanilla. Turn on the device, pour the ingredients
into the bowl. Mix until thickened, i.e. approx. 30–40
minutes.
C. Strawberry sorbet (8 servings of half a glass: 250 g
or half a litre of fresh strawberries, halved (without
stalks), a tablespoon and half of freshly squeezed
lemon juice, half a glass of sugar, 1 glass of whole
milk, 1 glass of well-chilled heavy cream, 1 teaspoon
of vanilla extract for taste). Combine strawberries
with lemon juice and half of the measured amount
of sugar (about a quarter of a glass). Mix gently and
set aside for two hours. In a separate bowl, combine
the milk with the rest of the sugar. Add the thick
cream and strawberry juice. Turn on the device, pour
the ingredients into the bowl. Mix until thickened, i.e.
approx. 30–40 minutes. 5 minutes before the end,
add the chopped strawberries.
CAUTION: The ice cream will have a natural color,
slightly pink. If a darker color is desired, red food
coloring should be added dropwise until the desired
color is achieved.
D. Lemon sorbet (8 servings of half a glass: a glass
and half of sugar, a glass and half of water, 1 glass
of freshly squeezed lemon juice, 1 tablespoon of
finely chopped lemon zest). Mix sugar and water
in a small saucepan and bring to a boil. Cook over
low heat until the sugar dissolves (such a syrup can
be prepared in larger quantities and stored in the
refrigerator for a long time until used again). After
cooling, add lemon juice and lemon zest, stir until
ingredients are combined. Turn the device on, pour
the ingredients into the bowl. Mix until thickened, i.e.
approx. 30–40 minutes.
E. Chocolate frozen yogurt (8 servings of half a glass: 1
glass of full-fat milk, 180 g of chopped dark or semi-
sweet chocolate, 2 glass of low fat vanilla yogurt,
a quarter of a glass with sugar).
Rev. 28.05.2024
EN
Add milk and chocolate to a blender or mixer and
mix until smooth. Add yogurt and sugar and mix until
smooth. Turn the device on, pour the ingredients
into the bowl. Mix until thickened, i.e. approx. 50–60
minutes.
3.3.3. TROUBLESHOOTING
Problem Possible cause Solution
Once the
production
Wait about
of ice cream Ice cream mass
a minute and try
is finished, too hard.
again.
it cannot be
served.

3.4. CLEANING AND MAINTENANCE

a) Unplug the mains plug and allow the device to cool
completely before each cleaning, adjustment or
replacement of accessories, or if the device is not
being used. Wait for the rotating elements to stop.
b) Use only mild, food-safe detergents to wash the
device.
c) After cleaning the device, all parts should be dried
completely before using it again.
d) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
e) Do not spray the device with a water jet or submerge
it in water.
f) Do not allow water to get inside the device through
vents in the housing of the device.
g) Clean the vents with a brush and compressed air.
h) Use a soft, damp cloth for cleaning.
i) Do not use sharp and/or metal objects for cleaning
(e.g. a wire brush or a metal spatula) because they
may damage the surface material of the appliance.
DISPOSING OF USED DEVICES
Do not dispose of this device in municipal waste systems.
Hand it over to an electric and electrical device recycling
and collection point. Check the symbol on the product,
instruction manual and packaging. The plastics used
to construct the device can be recycled in accordance
with their markings. By choosing to recycle you are
making a significant contribution to the protection of our
environment. Contact local authorities for information on
your local recycling facility.
