tension mechanism, the spool (11)
must have stopped completely before
you restart the device. If the line is ini-
tially longer than the cutting circle,
the line cutter (27) will automatically
shorten them to the correct length.
Procedure (Fig. D)
1. Check the nylon line regularly for
damage and make sure the cutting
line still has the length specified by
the line cutter.
2. If no line ends are visible:
Replace the spool (see
Maintenance, p. 30).
3. Adjust the line length manually:
Remove the battery (17) from the
device!
Lightly pull on the line end and
press the locking button (25) re-
peatedly if necessary until the line
end protrudes beyond the line cut-
ter (27).
Checking the battery
charge level
LEDs
red, orange, green Battery charged
red, orange
red
1. Press the button (19) next to the
charge level indicator button (20)
on the battery (17).
The LEDs of the charge level in-
dicator show how much charge re-
mains in the battery.
2. Charge the battery (17) when only
the red LED on the charge level in-
dicator (20) is illuminated.
Charging the battery
See also the charger instruction
manual.
28
Meaning
Battery partially
charged
Battery needs to
be charged
Notes
• If warm, allow the battery to cool
before charging.
• Do not expose the battery to dir-
ect sunlight for long periods and
do not place it on a radiator (max.
50°C).
Charging the battery
1. Remove the battery (17) from the
device.
2. Push the battery (17) into the char-
ging slot of the battery charger
(16).
3. Connect the battery charger (16) to
a power outlet.
4. After charging, disconnect the bat-
tery charger (16) from the mains.
5. Pull the battery (17) out of the bat-
tery charger (16).
Control LEDs on the charger (16):
green red
lights up —
— lights up Battery is char-
— flashes
flashes flashes
Operation
Working with the device
WARNING! Risk of injury! Pay at-
tention to the following instructions.
• Do not cut damp or wet grass.
• Before starting the device, make
sure that the cutting unit is not in
contact with stones, debris or oth-
er foreign objects.
Meaning
• Battery is fully
charged
• stand-by (No
battery inser-
ted)
ging
Battery is over-
heated
Battery is defect-
ive
