1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new tool brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this device assumes no lia-
bility for damage to the device or caused by the device
arising from:
• Improper handling
• Failure to comply with the operating instructions.
• Repairs carried out by third parties, unauthorised
specialists.
• Installing and replacing non-original spare parts,
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your device and to use it for its intended
purpose.
The operating manual includes important instructions
for safe, proper and economic operation of the device,
for avoiding danger, for minimising repair costs and
downtimes, and for increasing the reliability and ex-
tending the service life of the device.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the device in your country.
Keep the operating manual at the device, in a plastic
sleeve, protected from dirt and moisture. They must be
read and carefully observed by all operating personnel
before starting the work.
The device may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
34 | GB www.scheppach.com
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such machines must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Device description, (Fig. 1-23)
1. Adjusting knob for saw belt tension
2. Housing door
3. Door lock (top)
4. Saw band guard
5. Saw band guide
6. Parallel stop
7. Guide rail
8. Door lock (bottom)
9. Hand wheel for cutting speed
10. Transport handle
11. Travel fixture
12. Machine stand
13. Main frame
14. On/off switch
15. Quick-release lever, saw belt tension
16. Tailstock holder
17. Wing screw
18. Adjustment screw, angle adjustment
19. Electrical power connection
20. Engine
21. Suction port
22. Adjusting knob, angle setting, saw bench
23. Quick-release lever, angle adjustment
24. Saw table
25. Table inlay
26. Saw band
27. Adjustment handle for the saw band guard
28. Adjusting knob for top band wheel
29. Mounting plates for handle
30. Transverse cutting gauge
31. Thrust bearing mount
32. Top and bottom guide rollers
33. Parallel stop clamping lever
34. Door arrester
3. Scope of delivery (Fig. 3)
• Band saw
• Parallel stop (6)
• Guide rail (7)
• Hand wheel for cutting speed (9)
• Transport handle (10)
• 1x Travel fixture (11)
• Saw table (24)
• 2x mounting plates for handle (29)
• Transverse cutting gauge (30)
• 4x wing screws (35)
• 4x frame legs (36)
• 1x intermediate plate (37)
• 4x wing screw washers (38)
• 2x swivel part screws (M6 x 12) (39)
• 2x swivel part washers (40)
• 1x swivel part fixing screw (41)
• 1x Locking nut for handwheel for cutting speed (42)
• 1x Washer handwheel for cutting speed (43)
• 24x screws for machine stand and mounting plates
(M6 x 12) (44)
• 24x nuts for machine stand and mounting plates
(M6) (45)
• 24x washers for machine stand and mounting plates
(46)
• 4x screws for travel fixture (M8 x 16) (47)
• 4x nut for travel fixture (48)
• 4x screws for saw table (M8 x 16) (49)
• 4x washers for saw table (50)
• 4x foot caps (51)
• 1x push stick (52)
• 4x mounting bracket for attachment of the band
saw (53)
• Swivel part (54)
• Locking pin (c)
• Hexagon spanner - size 10/ 13
• Allen key, size 4
• Allen key, SW 5
• Original operating manual
4. Proper use
The band saw is used for the longitudinal and trans-
verse cutting of timbers or wood-like workpieces.
Round materials may only be cut using suitable hold-
ing devices (not included in the scope of delivery).
The machine may only be used in the intended man-
ner. Any use beyond this is improper.
www.scheppach.com
The user/operator, not the manufacturer, is responsi-
ble for damages or injuries of any type resulting from
this.
Only saw bands that are suitable for the machine may
be used. An element of the intended use is also the
observance of the safety instructions, as well as the
assembly instructions and operating information in the
operating manual.
Persons who operate and maintain the machine must
be familiar with the manual and must be informed
about potential dangers. In addition, the applicable
accident prevention regulations must be strictly ob-
served. Other general occupational health and safe-
ty-related rules and regulations must be observed.
The liability of the manufacturer and resulting dam-
ages are excluded in the event of modifications of the
machine.
Despite use as intended, specific risk factors cannot
be entirely eliminated. Due to the design and layout of
the machine, the following risks remain:
• Hearing damage when the necessary hearing pro-
tection is not used.
• Harmful emissions of wood dusts during use in en-
closed areas.
• Risk of accident due to contact with the hands in the
uncovered cutting area of the tool.
• Danger of injury during a tool change (cutting haz-
ard).
• Danger due to the ejection of workpieces or parts
of the workpiece.
• Crushing of fingers.
• Danger due to kick-back.
• Tilting of the workpiece due to insufficient workpiece
support surface.
• Touching the cutting tool.
• Ejection of branches and workpiece parts.
• The machine may only be operated with original ac-
cessories and original tools from the manufacturer.
• Any use beyond this is improper use. The manufac-
turer is not responsible for the resulting damages;
the user solely bears the risk.
Please note that our equipment was not designed with
the intention of use for commercial or industrial pur-
poses. We assume no guarantee if the device is used
in commercial or industrial applications, or for equiv-
alent work.
