EN
Problem
The product mows for shorter periods than
usual between charges.
Short mowing and charging times.
The product often moves in circles or spirals.
The product returns to the charging station
during mowing.
Uneven mowing results
LED STATUS INDICATOR ON THE CHARGING STATION
The LED status indicator on the charging station must show a solid or flashing GREEN for a correct installation. If not, follow the below instructions:
LED Status Indicator
Solid GREEN
Flashing GREEN
Solid RED
Flashing RED
No LED
22
ROBOTIC MOWER — RM4000E
Cause
1. Grass or other foreign object blocks the
blades.
2. The battery is spent.
3. Dull blades. More energy is needed when
cutting the grass.
The battery is spent.
Spiral cutting is a natural part of the product's
movement pattern.
The rain sensor switch is triggered
unintentionally.
1. The product works too few hours per day.
2. The work area is too large.
3. Dull blades
4. Long grass in relation to the set cutting
height.
5. Accumulation of grass by the blades or
around the motor shaft.
Meaning
Good signal. The product is not charging.
Good signal. The product is charging.
The product is not charging.
The boundary wire is not connected to the
charging station.
The product is not charging.
Damage in the boundary wire.
The product is in charging.
The boundary wire is not connected to the
charging station.
The product is charging.
Damage in the boundary wire.
The charging station is not powered.
Solution
1. Remove and clean the chassis and blades.
2. Contact EGO service center.
3. Replace the blades.
Contact EGO service center.
Adjust the intensity of spiral cutting.
This function can be disabled if necessary.
Refer to 10.5.2 Spiral cutting mode .
Check the rain sensor switch. This function
can be disabled if necessary Refer to
10.9.1 Rain sensor setting .
1. Increase the mowing time. Refer to
10.3.2 To set the schedule .
2. Try limiting the work area or extending
the schedule. Refer to 10.3.2 To set the
schedule .
3. Replace all the blades and screws.
4. Increase the cutting height and then
successively lower it.
5. Check that the blades rotate freely and
easily. If not, screw off the blades and
remove grass and foreign objects.
Action
No action.
No action.
Make sure that the boundary wire is correctly
installed in the charging station. Refer to
4.1 To install the boundary wire .
Find out where the damage is. Replace the
damaged section with new boundary wire.
Make sure that the boundary wire is correctly
installed in the charging station. Refer to
4.1 To install the boundary wire .
Find out where the damage is. Replace the
damaged section with new boundary wire.
Check socket is powered, and that adapter
and cable are connected and free from
damage.
