WARNING: Do not use the product when persons, especially
children, or animals, are in the work area.
BEFORE STARTING THE PRODUCT
1.
Make sure the product charge is more than 50% for the first
time.
2.
The LED status indicator on the charging station must show a
solid or flashing GREEN for a correct installation.
3.
The product operates within the set schedule, refer to
10.3.2 To set the schedule (pressing the START button outside
of scheduled work times will mean machine remains in station
until next schedule operation).The product operates immediately
if setting the override schedule, refer to 10.3.5 To override
schedule .
4.
Make sure the product is in the selected work area, refer to
10.5 Operation Mode Setting.
5.
Make sure the product is within the boundary wire.
TO START THE PRODUCT
1.
Push the STOP button to open the LCD screen cover.
2.
Press the POWER button to switch ON the product.
3.
Enter the PIN code.
4.
Press the START button and close the cover.
NOTE: Always press the START button before closing the cover to start
the product.
NOTE: Before the first operation the machine needs to complete the
mapping cycle.
TO PARK THE PRODUCT
The product stays in the charging station for set park time and then
automatically goes back to the usual operation as per schedule.
1.
Press the PARK button to enter park mode.
2.
Tap
to set park time.
3.
Tap
to confirm.
TO STOP THE PRODUCT
Push the STOP button to make the product and the cutting motor stop.
TO SWITCH OFF THE PRODUCT
Push the STOP button to open the LCD screen cover.
1.
Press the POWER button for more than 2 seconds to switch OFF
2.
the product.
NOTE: You can also press the POWER button for more than 4 seconds
to switch off the product forcedly if you do not enter the PIN code.
TO RECALL THE PRODUCT TO THE CHARGING STATION
When pressing the HOME button on the charging station the LED status
indicator on the charging station will flash quickly for 3 times and the
product will return to near the charging station.
MAINTENANCE
WARNING: To avoid serious personal injury, always switch off the
mower, and ensure that all moving parts have come to a complete
standstill, before cleaning, performing any maintenance or transporting
the mower.
WARNING: When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause product damage.
To ensure safety and reliability, all repairs should be performed by a
qualified service technician.
WARNING: Always wear protective gloves when performing any
maintenance on the product blades.
For better operation and longer service life, make sure to clean the
product regularly and replace worn parts.
When the product is first used, the blades should be inspected once a
week.
It is important that the blades rotate easily. The edges of the blades
should not be damaged. The lifetime of the blades varies immensely
and depends on for instance:
◾
Operating time and size of the work area.
◾
Type of grass and seasonal growth.
◾
Soil, sand and use of fertilizers.
◾
The presence of objects such as cones, windfalls, toys, tools,
stones, roots and the like.
NOTE: Working with blunt blades gives a poorer mowing result. The
grass is not cut cleanly and more energy is needed resulting in the
product not mowing such a large area.
Clean the product
CAUTION: Never use a high-pressure washer to clean the product
or charging station. Never use solvents for cleaning.
Chassis and blades
Inspect the blades once a week.
1.
Switch off the product.
2.
Lift the product onto its side.
3.
Clean the blades and chassis using a dish brush. At the same
time, check that the blades are intact and rotates freely.
To clean the wheels
The product does not operate satisfactorily in slopes if the wheels are
blocked with grass.
◾
Use a soft brush to clean the wheels
To clean the body of the product
◾
Use a moist cloth and a weak soap solution to clean the body of
the product.
To clean the charging station
WARNING: Disconnect the power supply from the power outlet
before maintenance.
ROBOTIC MOWER — RM4000E
EN
17
