5.
Put the low-voltage cable in the ground with stakes or bury the
cable. Refer to 5 To put the wire into position with stakes or 6 To
bury the boundary wire .
6.
Attach the charging station to the ground with the supplied
6 screws.
5. To put the wire into position with stakes
CAUTION: Make sure that the stakes hold the boundary wire
against the ground.
Cutting the Grass around the boundary prior to installing the boundary
wire will make this process easier.
CAUTION: Cutting the grass too low right after installation can
damage the wire insulation. Damage to the insulation may not cause
disruptions until several weeks or months later.
1.
Put the boundary wire on the ground.
2.
Put the stakes at a maximum of 1 m distance from each other.
NOTE: Use additional pegs where gradient changes to ensure wire
remains flat against ground (Fig. R).
3.
Attach the stakes to the ground with a hammer or a plastic
mallet.
NOTE: The wire is overgrown with grass and not visible after a few
weeks.
6. To bury the boundary wire
◾
Cut a groove in the ground with an edge cutter or a straight
shovel, or use specialized cable laying machine
◾
Put the boundary wire 1-20 cm into the ground.
Your EGO Dealer can support with boundary wire installation.
7. To extend the boundary wire (Fig. S)
NOTE: Extend the boundary wire if it is too short for the work area. Use
original EGO cable and couplers.
1.
Disconnect the charging station from the power outlet.
2.
Cut the boundary wire with a pair of wire cutters where it is
necessary to install the extension.
3.
Add wire where it is necessary to install the extension.
4.
Put the boundary wire into position.
5.
Put the wire ends into a coupler.
NOTE: Make sure that you can see the ends of the boundary wire
through the transparent area of the coupler.
6.
Push down the cover on the coupler with adjustable pliers to
attach the wires in the coupler.
7.
Put the boundary wire into position with stakes. Coupler can be
buried to ensure it does not come into contact with robot during
mowing.
8.
Connect the charging station to the power outlet.
8. After the installation of the product
8.1 To do a visual check of the charging station
Make sure that the LED status indicator on the charging station glows
solid GREEN.
If the LED status indicator does not glow solid green, do a check of the
installation. Refer to 4.2 To install the charging station and LED STATUS
INDICATOR ON THE CHARGING STATION in this manual .
8.2. To charge the product
When the product is new or has been stored for a long period, the
battery can be empty and needs to be charged before starting.
WARNING: Only charge the product using a charging station and
a power supply which is intended for it. Incorrect use may result in
electric shock, overheating or leakage of corrosive liquid from the
battery. In the event of leakage of electrolyte flush with water and seek
medical help if it comes in contact with the eyes etc.
1.
Place the product in the charging station.
2.
Slide the product in as far as possible to ensure proper contact
between the product and the charging station.
3.
The flashing GREEN on the charging station indicates that
charging is in progress.
8.3 To define the basic settings
Before the product starts to operate for the first time, you must
commission the machine and define the settings.
Push the STOP button to open the LCD screen cover.
1.
Press the POWER button to switch ON the product.
2.
3.
Follow on screen prompts to define settings: language, safe &
legal statements, country & time zone, unit format, pin setting,
and cutting height setting.
NOTE: It is not possible to use 0000 as PIN code.
4.
When commissioning is completed main menu will be displayed.
9. EGO Connect
TM
The product is compatible with EGO Connect
schedule can be set remotely using EGO Connect
NOTE: Make sure the Bluetooth
®
is enabled on mobile devices when
using remote control function.
Your RM4000E has Long-range cellular connectivity and Short-range
Bluetooth
connectivity.
®
9.1 To install EGO Connect
TM
1.
Download EGO Connect
on your mobile device or scan
TM
QR Code below.
2.
Create a new account in EGO Connect
account, skip to step 4.
ROBOTIC MOWER — RM4000E
EN
. All settings and mowing
TM
TM
.
. If you already have an
TM
11
