PRODUCT OPERATION GUIDE

Product Storage

1. Move the Seat Cushion Assembly (D) to the position shown in the figure (to prevent
the seat cushion assembly from falling down quickly when the product is folded, which
may damage the product).
2. Adjust the Monitor (E) in the direction of the arrow so that it is flat against the Main
Frame (A).
3. Hold the Rear Connecting Plate Assembly (11) tightly with your hands and slowly pull
it up as indicated by the red arrow.
A
Product Movement
1. First move the Seat Cushion Assembly (D) to the position shown in the figure (to pre-
vent the Seat Cushion Assembl from falling quickly when the product is folded and da-
maging the product).
2. Turn the Monitor (E) in the direction of the arrow to make it flat against the Main Frame (A).
3. Hold the Left and Right Slide Rail (B/C) tightly with your hands, lift them up slowly,
and move them to the required position.
E
11
D
E
D
B/C
11
