PRODUCT OPERATION GUIDE

PRODUCT OPERATION GUIDE
Water Regulation InstructionF
1. Remove the plug from the water tank.
2. Water Filling: Insert the water pump head into the water tank, then insert the water
pipe into the bucket. Refer to the numerical scale on the side of the water tank to mea-
sure the water level in the tank (as shown in Figure A).
3. Water Drawing: Place a bucket next to the machine, and use the water pump to draw
water from the tank into the bucket (as shown in Figure B).
4. Insert the plug back into the top water tank, and use a dry cloth to wipe dry any water
stains around the tank.
·Notes: Please ensure the electric water pump is fully charged before use.
·Only non-distilled water should be poured into the water tank, along with adding water
purification tablets. Do not use low-quality purification tablets or bleach to avoid dam-
aging the water tank.
·Add water purification tablets every 6 months or as needed. If the water quality beco-
mes very turbid, please replace the water in the tank.
·The water drained from the tank is not suitable for reuse and should be treated as
wastewater.
26
Water Level Scale:
10
·The water level scale is on the side of the water tank. The maximum water filling level is
marked by 6 levels. Do not exceed this numerical line.
·Resistance depends on the amount of water in the tank (1 level of water represents the
lowest resistance, while 6 levels of water represent the highest resistance).
Figure A
35
36
MAX FILL
6
5
WATER LEVEL
4
R E S I S T A N C E
3
RESIS.
2
MIN. FILL
1
35
26
36
Figure B
