7.8 Attaching the Chain Box with a Suspension Eye (Optional)
1. Place the chain box on the main body (11.1) with
a suspension eye.
2. Tighten the screw (11.2).
3. Attach the lifting device to the transport device
with the suspension eye (1).
7.9 Raising the Load
WARNING
Falling objects due to insufficient vacuum
Serious injury or death!
Before lifting the load, ensure that the working vacuum of -0,2 bar has been attained.
•
The ratio of lifting time to ventilation time (releasing) must be 2/3 to 1/3.
• Maximum lifting time: 2 minutes, followed by 1 minute of free suction.
7.9.1 Manual Handling
The lifting device must be lifted by two operators using two operator handles.
